74LVC16373ADGG

16-bit D-type transparent latch, 3.6V, 1A, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.50~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	4.00 / Piece
101 ~ 200 :	3.60 / Piece
201 ~ 300 :	3.50 / Piece

PartNumber:: 74LVC16373ADGG

Brand:: NXP - NXP | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 500/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-03-29

From Other Seller

Part Number:74LVC16373ADGG
US $3.50 - 4.00
74LVC16373ADGGRG4 - IC, 16BIT D-LATCH, 3-STATE, TSSOP-48

US $0.00 - 0.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 74LVC16373ADGG is a 16-bit D-type transparent latch featuring separate D-type inputs for each latch and 3-State outputs for bus oriented applications. The 74LVC16373ADGG consists of 2 sections of eight D-type transparent latches with 3-State true outputs. The 74LVC16373ADGG bus hold data inputs eliminates the need for external pull up resistors to hold unused inputs.

Parametrics

74LVC16373ADGG absolute maximum ratings: (1) DC supply voltage VCC: -0.5V to +6.5V; (2) DC input diode current IIK: -50mA (VI＜0): -50mA; (3) DC input voltage VI: -0.5V to +6.5V; (4) DC output diode current IOK: ±50mA ( VO＞VCC or Vo＜0) : -0.5 to Vcc +0.5V, -0.5V to 6.5V; (5) DC output source or sink current Io: ±50mA ( Vo=0 to Vcc) ; (6) DC Vcc or GND current, IGND, ICC: ±100mA; (7) Storage temperature range Tstg: -65°C to +150°C; (8) Power dissipation per package PTOT above +70°C derate linearly with 8 mW/K: 500mW, above +60°C derate linearly with 5.5 mW/K: 500mW.

Features

74LVC16373ADGG features: (1) 5V tolerant inputs/outputs for interfacing with 5V logic; (2) Wide supply voltage range of 1.2V to 3.6V; (3) Complies with JEDEC standard no. 8-1A; (4) CMOS low power consumption; (5) TMMULTIBYTE flow-through standard pin-out architecture; (6) Low inductance multiple power andground pins for minimum noise and ground bounce; (7) Direct interface with TTL levels; (8) All data inputs have bus hold (74LVCH167373A only) ; (9) High impedance when Vcc=0.
