Product Summary

AML8726‐M3 is an advanced connected multimedia processor designed for Tablet/MID, Set Top Box (STB), TV and high‐end media player applications. It integrates powerful CPU/GPU, and a state‐of‐the‐art video decoding engine with all major peripherals to form the ultimate low power multimedia SoC.

Parametrics

AML8726-M3 absolute maximum ratings: (1)1.2V Core Supply Voltage 1.4 V; (2)1.5V Supply Voltage: 1.65 V; (3)2.5V Supply Voltage: 2.75 V; (4)3.3V Supply Voltage: 3.63 V; (5)Input voltage, VI: ‐0.5 ~ VDD+0.3 V; (6)Junction Temperature: TBD °C.

Features

AML8726-M3 features: (1)ARM Cortex乚A9 CPU up to 1GHz frequency and 2500DMIPS; (2)ARMv7 instruction set, multi乚issue superscalar, out-of-order architecture; (3)32KB instruction cache and 32KB data cache; (4)128KB Unified L2 cache; (5)Advanced NEON and VFP co-processor; (6)Memory Management Unit; (7)Application based traffic optimization using internal QoS-based switching fabrics.

Diagrams

AML8726-M3 block diagram
