Product Summary
The HSMM-A100-S00J1 is a Surface Mount LED Indicator packaged in the industry standard PLCC-2 package. The SMT LED has high reliability performance and are designed to work under a wide range of environmental conditions. This high reliability feature makes the HSMM-A100-S00J1 ideally suited to be used under harsh interior automotive as well as interior signs application conditions. The applications of the HSMM-A100-S00J1 include Interior automotive, Electronic signs and signals, Office automation, home appliances, industrial equipment.
Parametrics
HSMM-A100-S00J1 absolute maximum ratings: (1)DC Forward Current: 30 mA; (2)Peak Forward Current: 100 mA; (3)Power Dissipation: 114 mW; (4)Reverse Voltage: 5 V; (5)Junction Temperature: 110℃; (6)Operating Temperature: -55 to +100℃; (7)Storage Temperature: -55 to +100℃.
Features
HSMM-A100-S00J1 features: (1)Industry standard PLCC-2 package; (2)High reliability LED package; (3)High brightness using AlInGaP and InGaN dice technologies; (4)Available in full selection of colors; (5)Super wide viewing angle at 120°; (6)Available in 8 mm carrier tape on 7 inch reel (2000 pieces); (7)Compatible with both IR and TTW soldering process.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HSMM-A100-S00J1 |
Avago Technologies |
Standard LED - SMD Green Epoxy Lens 525nm 350mcd |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
HSMM-A100-S00J1 |
Avago Technologies |
Standard LED - SMD Green Epoxy Lens 525nm 350mcd |
Data Sheet |
|
|
||||||||||||
|
HSMM-A100-S8PJ1 |
Avago Technologies |
Standard LED - SMD InGaN Green rn |
Data Sheet |
Negotiable |
|
||||||||||||
|
HSMM-A100-U4PJ1 |
Avago Technologies |
Standard LED - SMD InGaN Green |
Data Sheet |
|
|
||||||||||||
|
HSMM-A101-R00J1 |
Avago Technologies |
Standard LED - SMD Green Epoxy Lens 525nm 200mcd |
Data Sheet |
|
|
||||||||||||
|
HSMM-A101-R3PJ1 |
Avago Technologies |
Standard LED - SMD InGaN Green rn |
Data Sheet |
Negotiable |
|
||||||||||||
|
HSMM-A101-R7PJ1 |
Avago Technologies |
Standard LED - SMD InGaN Green rn |
Data Sheet |
Negotiable |
|
||||||||||||
