Product Summary

The MDM8220 is a MDM-PCB connector designed for use with flex circuitry, flat cable and printed circuit boards or multi-layer boards. The device uses the standard MDM metal shell and provide high density and high reliability in board-to-board, board-to-cable and cable-to-cable applications. The MDM8220 is available in 8 shell sizes with 9 to 100 contacts. Terminations may be straight (BS) or at 90° right angle (BR, CBR) board thickness. Jackpost mounting for use with locking hardware is also available.

Diagrams

MDM8220 block diagram
