Product Summary
The MP1482DS is a monolithic synchronous buck regulator. The device integrates two 130mW MOSFETs, and provides 2A of continuous load current over a wide input voltage of 4.75V to 18V. Current mode control provides fast transient response and cycle-by-cycle current limit. An adjustable soft-start prevents inrush current at turn-on, and in shutdown mode the supply current drops to 1 μA. The MP1482DS, available in an 8-pin SOIC package, provides a very compact solution with minimal external components. `
Parametrics
MP1482DS absolute maximum ratings: (1)Vin (Min): 4.75V; (2)Vin (Max): 18V; (3)lout (Max): 2A; (4)Isw Typ: 3.4A; (5)Iq (Typ): 1.3mA; (6)Vfb: 0.923V; (7)Freq 1: 340kHz.
Features
MP1482DS features: (1)2A Output Current; (2)Wide 4.75V to 18V Operating Input Range; (3)Integrated 130mΩ Power MOSFET Switches; (4)Output Adjustable from 0.923V to 15V; (5)Up to 93% Efficiency; (6)Programmable Soft-Start; (7)Stable with Low ESR Ceramic Output Capacitors; (8)Fixed 340kHz Frequency; (9)Cycle-by-Cycle Over Current Protection; (10)Input Under Voltage Lockout.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MP1482DS-LF |
Monolithic Power Systems (MPS) |
Switching Converters, Regulators & Controllers 2A, 18V Sync Step-Down DCDC |
Data Sheet |
|
|
||||||||||||
|
MP1482DS-LF-Z |
Monolithic Power Systems (MPS) |
Switching Converters, Regulators & Controllers 2A, 18V Sync Step-Down DCDC |
Data Sheet |
|
|
||||||||||||
