SN75451BP

SN75451BP, dual peripheral driver, PDIP, 7V, 300mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	1.00 / Piece
301 ~ 600 :	0.80 / Piece
601 ~ 1000 :	0.50 / Piece

PartNumber:: SN75451BP

Brand:: Texas Instruments - TI | Pack: PDIP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-12

From Other Seller

Part Number:SN75451BP
US $0.50 - 1.00
Quantity:

piece

Product Summary

The SN75451BP is a dual peripheral driver. It is designed for use in systems that employ TTL logic. The speed of the SN75451BP is equal to that of the SN75450 family, and the parts are designed to ensure freedom from latch-up. Diode-clamped inputs simplify circuit design. Typical applications of the SN75451BP include high-speed logic buffers, power drivers, relay drivers, lamp drivers, MOS drivers, line drivers, and memory drivers.

Parametrics

SN75451BP absolute maximum ratings: (1)Supply voltage: 7 V; (2)Input voltage: 5.5 V; (3)Off-state voltage applied to open-collector outputs: 12 V; (4)Operating free-air temperature range: 0℃ to 70℃; (5)Storage temperature range: –65℃ to 150℃; (6)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.

Features

SN75451BP features: (1)Characterized for Use to 300 mA; (2)High-Voltage Outputs; (3)No Output Latch-Up at 20 V (After Conducting 300 mA); (4)High-Speed Switching; (5)Circuit Flexibility for Varied Applications; (6)TTL-Compatible Diode-Clamped Inputs; (7)Standard Supply Voltages; (8)Plastic DIP (P) With Copper Lead Frame Provides Cooler Operation and Improved Reliability; (9)Package Options Include Plastic Small-Outline Packages, Ceramic Chip Carriers, and Standard Plastic and Ceramic 300-mil DIPs.
