Product Summary
The AduM1301ARWZ is 3-channel digital isolator based on Analog Devices’iCoupler technology. Combining high speed CMOS and monolithic transformer technology, the isolation component provides outstanding performance characteristics superior to alternatives such as optocoupler devices. The AduM1301ARWZ provides three independent isolation channels in a variety of channel configurations and data rates.
Parametrics
AduM1301ARWZ absolute maximum ratings: (1)Storage Temperature: –65°C +150 °C; (2)Ambient Operating Temperature: –40°C +105 °C; (3)Supply Voltages: –0.5V to +7.0V; (4)Input Voltage: –0.5V to VDDI + 0.5V; (5)Output Voltage: –0.5V to VDDO + 0.5V; (6)Average Output Current, Per Pin: Side 1:–23mA to +23mA, Side 2:–30mA to +30mA; (7)Common-Mode Transients: –100kV/μs to +100kV/μs.
Features
AduM1301ARWZ features: (1)Low power operation; (2)Bidirectional communication; (3)3 V/5 V level translation; (4)High temperature operation: 105°C; (5)High data rate: dc to 90 Mbps (NRZ); (6)High common-mode transient immunity: >25 kV/μs; (7)Output enable function; (8)Wide body 16-lead SOIC package, Pb-free models available; (9)Safety and regulatory approvals; (10)Precise timing characteristics.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ADUM1301ARWZ |
|
IC DIGITAL ISOLATOR 3CH 16-SOIC |
Data Sheet |
|
|
||||||||||||||||
|
ADUM1301ARWZ-RL |
|
IC DGITAL ISOLATOR 3CH 16-SOIC |
Data Sheet |
|
|
||||||||||||||||
