BCM2045

BCM2045, monolithic, single-chip, stand-alone baseband processor, BGA, BroadcomCorporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	3.00 / Piece
301 ~ 600 :	2.80 / Piece
601 ~ 1000 :	2.50 / Piece

PartNumber:: BCM2045

Brand:: BroadcomCorporation - BROADCOM | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-16

From Other Seller

Part Number:BCM2045
US $2.50 - 3.00
BCM2045SB2KFBG

US $1.70 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The BCM2045 is a monolithic, single-chip, stand-alone baseband processor with an integrated 2.4-GHz transceiver for Bluetooth 2.0 + EDR applications. It is fully compliant with the Bluetooth specification and completely backward-compatible with any Bluetooth version 1.1 or 1.2-based system. It eliminates the need for external flash memories and active components by integrating critical components into the device, thus minimizing the footprint and system cost of implementing a Bluetooth system. The applications of the BCM2045 include Cellular and mobile communication devices, PDA and low-power embedded communication devices, PC and integration on PC mother board applications, Package types available, 95-pin fpBGA package (6 mm x 6 mm); 65-pin fpBGA package (5 mm x 5 mm), Wafer scale flip chip packaging.

Features

BCM2045 features: (1)World’s first Bluetooth 2.0 + EDR solution in 0.13 um CMOS technology; (2)Fully integrated balun and T/R switch eliminates all external RF matching components; (3)Supports class 1, 2, and 3 designs; (4)Fully supports the Bluetooth 1.1, 1.2, and 2.0 standards including 1, 2, and 3 Mbps EDR operation; (5)Lowest current consumption in all modes of operation; (6)ROM-based solution eliminates external flash and/or EEPROM memory; (7)Highest available Bluetooth radio performance of any singlechip solution; (8)88 dBm receiver sensitivity using EDR communication; (9)Programmable output power up to +7 dBm; (10)Minimized external BOM requirements are less than 10 external passive components; (11)Supports UART, USB, SDI, and SPI HCI transports; (12)Fractional-N frequency synthesizer supports any crystal or TCXO source from 12 to 40 MHz; (13)Automatic calibration and frequency detection of crystal frequency.
