Product Summary

The BCM2050KMLG is a two System-On-Chips, integrated access switch processor. The BCM2050KMLG also features an on-chip, five-port 10/100 Ethernet switch with management features. This switch processor also offers extensive processor and interface integration featuring an integrated 200-MHz MIPS32. core, UART, flash and SDRAM/DDRAM interfaces. The BCM2050KMLG also supports a PCI interface.

Features

BCM2050KMLG features: (1)Compact, sophisticated, and low-cost access point includes chipset: BCM4712, BCM2050, and AC101L; (2)10/100 Ethernet LAN port with Auto-MDIX; (3)Integrated MAC/baseband; (4)2.4 GHz PCB patch antenna; (5)Antenna diversity supports both integrated and external antennas; (6)RF test point footprint supports characterization; (7)Provides USB device functionality and USB 1.1 host for print server and camera server functionality; (8)Supports flash memory from 256 KB to 2 MB, plus 4-MB or 8-MB SDRAM.

Diagrams

BCM2050KMLG block diagram
