Product Summary
The BCM4320SKFBG is an Intensi-fi Gigabit Ethernet Draft-802.11n Processor. It integrates a powerful 300 MHz/500 DMIPS (estimated) MIPS32 core with 4-way set associative 32 KB instruction cache, a 32 KB 2-way set associative data cache, and a 4 KB prefetch cache. An enhanced 10/100/1000 Gigabit Ethernet MAC controller with TCP Segmentation and checksum Offload (TSO) hardware acceleration engine substantially enhances system throughput.
Features
BCM4320SKFBG features: (1)Advanced 500 DMIPS/300-MHz MIPS32 core, 4-way set associative 32-KB I-Cache; 2-way set associative 32-KB D-Cache; 4-KB Read-Ahead Cache; MMU/TLB support for Linux Advanced Gigabit Ethernet MAC, Hardware TCP segmentation and Checksum offload; GMII, RGMII, and MII PHY connectivity; (2)Two USB2.0 High-speed host ports; (3)One USB2.0 High-speed device port; (4)DDR SDRAM controller, 16/32-bit DDR266 and 133-MHz SDRAM support; 8 MB to 512 MB capacity; Support for 8/16/32-bit wide memory devices; (5)PCI 2.3 Host interface (32 bit/33?7 MHz), Supports four PCI bus masters; Optional 5V-tolerant operation (PCI 2.2 support); (6)Advanced GPIO interface, All GPI supports interrupt triggering capability; (7)Dual RS232 UART; (8)2.4W Low-power design.
Diagrams
