Product Summary

The ADP-68HC711 is a Small Form Factor (SFF) transceiver comply with the 2x5 standard package defined by the Small Form Factor Multi-Sourcing Agreement (MSA)1. The ADP-68HC711 is simultaneously compatible with Gigabit Ethernet as specified in IEEE Std 802.32 and Fibre Channel FC-PI-2 10.03. The device is RoHS compliant and lead-free per Directive 2002/95/EC4 and Finisar Application Note AN-2038. The applications of the ADP-68HC711 include 1.25 Gb/s 1000Base-SX Ethernet, Dual Rate 1.063/2.125 Gb/s Fibre Channel.

Parametrics

ADP-68HC711 absolute maximum ratings: (1)Maximum Supply Voltage, Vcc: -0.5 to 4.0V; (2)Storage Temperature, TS: -40 to 85℃; (3)Case Operating Temperature, TOP: 0 to 70℃; (4)Relative Humidity, RH: 0 to 85%; (5)Hand Lead Soldering Temperature/Time: 260/10℃/s; (6)Wave Lead Soldering Temperature/Time: 260/10℃/s.

Features

ADP-68HC711 features: (1)Up to 2.125 Gb/s bi-directional data links; (2)Standard 2x5 pin SFF footprint (MSA compliant); (3)850nm Oxide VCSEL laser transmitter; (4)Duplex LC connector; (5)RoHS compliant and Lead Free; (6)Up to 500m on 50/125μm MMF, 300m on 62.5/125μm MMF; (7)Metal enclosure, for lower EMI; (8)Single 3.3V power supply; (9)Low power dissipation <750mW; (10)Commercial operating temperature range: 0℃ to 70℃.

Diagrams

ADP-68HC711 block diagram
