Product Summary

The FTLF8528P2BNV is a SFP+ transceiver designed for use in Fibre Channel links up to 8.5 Gb/s data rate over multimode fiber. The FTLF8528P2BNV-EM is compliant with FC-PI-4 Rev. 7.001 and SFF-8472 Rev 10.13, and compatible with SFF-84322 and applicable portions of SFF-8431 Rev. 1.34. The product is RoHS compliant and lead-free per Directive 2002/95/EC5 and Finisar Application Note AN-2038. The application of the FTLF8528P2BNV includes Tri-Rate 2.125/4.25/8.5 Gb/s Fibre Channel.

Parametrics

FTLF8528P2BNV-EM absolute maximum ratings: (1)Maximum Supply Voltage, Vcc: -0.5 to 4.0 V; (2)Storage Temperature, TS: -40 to 85℃; (3)Case Operating Temperature, TA: 0 to 70℃; (4)Relative Humidity, RH: 0 to 85 %.

Features

FTLF8528P2BNV-EM features: (1)Up to 8.5 Gb/s bi-directional data links; (2)Hot-pluggable SFP+ footprint; (3)Built-in digital diagnostic functions; (4)850nm Oxide VCSEL laser transmitter; (5)Duplex LC connector; (6)RoHS compliant and Lead Free; (7)50m on 50/125μm MMF; (8)150m on high-bandwidth 50/125um (OM3) MMF; (9)Metal enclosure, for lower EMI; (10)Single 3.3V power supply; (11)Extended operating temperature range: -5℃ to 85℃.

Diagrams

FTLF8528P2BNV-EM block diagram
