HEF4013BT

HEF4013BT, dual D-type flip-flop, SO, -0.5 to 18V, 50mA, NXP Semiconductors

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	3.00 / Piece
301 ~ 600 :	2.50 / Piece
601 ~ 1000 :	2.00 / Piece

PartNumber:: HEF4013BT

Brand:: NXP - NXP | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-28

From Other Seller

Part Number:HEF4013BT
US $2.00 - 3.00
HEF4013BT

US $0.01 - 6.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The HEF4013BT is a dual D-type flip-flop which features independent set direct (SD), clear direct (CD), clock inputs(CP) and outputs (O, O). Data is accepted when CP is LOW and transferred to the output on the positive-going edge of the clock. The active HIGH asynchronous clear-direct (CD) and set-direct (SD) are independent and override the D or CP inputs. The outputs of HEF4013BT are buffered for best system performance. Schmitt-trigger action in the clock input makes the circuit highly tolerant to slower clock rise and fall times. The applications of the HEF4013BT include: Automotive and industrial, Counters and dividers, Registers, Toggle flip-flops.

Parametrics

HEF4013BT absolute maximum ratings: (1)VDD supply voltage: min=-0.5V, max=+18V; (2)On the conditions of VI < -0.5 V or VI > VDD + 0.5 V, IIK input clamping current: max=±10mA; (3)VI input voltage: min=-0.5V, max=VDD + 0.5V; (4)On the conditions of VO < -0.5 V or VO > VDD + 0.5 V, IOK output clamping current: max=±10mA; (5)II/O input/output current: max=±10mA; (6)IDD supply current: max=50mA; (7)Tstg storage temperature: min=-65℃, max=+150℃; (8)Tamb ambient temperature: min=-40℃, max=+125℃; (9)P power dissipation per output: max=100mW.

Features

HEF4013BT features: (1)Tolerant of slow clock rise and fall times; (2)Fully static operation; (3)5 V, 10 V, and 15 V parametric ratings; (4)Standardized symmetrical output characteristics; (5)Operates across the automotive temperature range from -40 ℃ to +125 ℃; (6)Complies with JEDEC standard JESD 13-B.
