LPC2292FET144

LPC2292FET144, 16/32-bit ARM microcontroller, BGA, -0.5 to +2.5 V, 1.5W, 100mA, NXP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	3.00 / Piece
301 ~ 600 :	2.80 / Piece
601 ~ 1000 :	2.50 / Piece

PartNumber:: LPC2292FET144

Brand:: NXP - NXP | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-17

From Other Seller

Part Number:LPC2292FET144
US $2.50 - 3.00
Quantity:

piece

Product Summary

The LPC2292FET144 is a 16/32-bit ARM microcontroller with real-time emulation and embedded trace support, together with 256 kB of embedded high-speed flash memory. A 128-bit wide memory interface and a unique accelerator architecture enable 32-bit code execution at the maximum clock rate. For critical code size applications, the alternative 16-bit Thumb mode reduces code by more than 30% with minimal performance penalty.

Parametrics

LPC2292FET144 absolute maximum ratings: (1)VDD(1V8) supply voltage (1.8 V): -0.5 to +2.5 V; (2)VDD(3V3) supply voltage (3.3 V): -0.5 to +3.6 V; (3)VDDA(3V3) analog supply voltage (3.3 V): -0.5 to +4.6 V; (4)VIA analog input voltage: -0.5 to +5.1 V; (5)VI input voltage 5 V tolerant I/O pins: -0.5 to +6.0 V; (6)other I/O pins: -0.5 to VDD(3V3) + 0.5 V; (7)IDD supply current: 100 mA; (8)ISS ground current: 100 mA; (9)Tj junction temperature: 150℃; (10)Tstg storage temperature: -65 to +150℃; (11)Ptot(pack) total power dissipation: 1.5 W.

Features

LPC2292FET144 features: (1)Fast GPIO ports enable port pin toggling up to 3.5 times faster than the original device; (2)They also allow for a port pin to be read at any time regardless of its function; (3)Dedicated result registers for ADC(s) reduce interrupt overhead. The ADC pads are 5 V tolerant when configured for digital I/O function(s); (4)UART0/1 include fractional baud rate generator, auto-bauding capabilities and handshake flow-control fully implemented in hardware; (5)Buffered SSP serial controller supporting SPI, 4-wire SSI, and Microwire formats; (6)SPI programmable data length and master mode enhancement; (7)Diversified Code Read Protection (CRP) enables different security levels to be implemented. This feature is available in LPC2292/2294/00 devices as well; (8)General purpose timers can operate as external event counters.
