M29W800DB

flash memory, 2.7 to 3.6V, 10mA, TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	3.00 / Piece
301 ~ 600 :	2.80 / Piece
601 ~ 1000 :	2.50 / Piece

PartNumber:: M29W800DB

Brand:: STMicroelectronics - ST | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-07

From Other Seller

Part Number:M29W800DB
US $2.50 - 3.00
Quantity:

piece

Product Summary

The M29W800DB is a 8 Mbit (1Mb x8 or 512Kb x16) non-volatile memory that can be read, erased and eprogrammed. The M29W800DB is divided into blocks that can be erased independently so it is possible to preserve valid data while old data is erased. The M29W800DB is offered in SO44, TSOP48 (12 x20mm) , TFBGA48 6 x 9mm (0.8mm pitch) and TFBGA48 6 x 8mm (0.8mm pitch) packages.

Parametrics

M29W800DB absolute maximum ratings: (1) Temperature Under Bias TBIAS: -50 to 125°C; (2) Storage Temperature Tstg: -65 to 150°C; (3) Input or Output Voltage VIO: -0.6 to Vcc +0.6V; (4) Supply Voltage Vcc: -0.6 to 4V; (5) Identification Voltage VID: -0.6 to 13.5V.

Features

M29W800DB features: (1) supply voltage: VCC=2.7V to 3.6V for Program, Erase and Read; (2) Access times: 45, 70, 90ns; (3) programming time: 10μs; (4) program/erase controller; (5) common flash interface; (6) low power consumption.
