MAX4167ESA

MAX4167ESA, operational amplifier, 7V, 80mA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	5.00 / Piece
101 ~ 1000 :	4.00 / Piece
1001 ~ 10000 :	3.00 / Piece

PartNumber:: MAX4167ESA

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-19

From Other Seller

Part Number:MAX4167ESA
US $3.00 - 5.00
Quantity:

piece

Product Summary

The MAX4167ESA is a high-output-drive, precision, low-power, single- supply, rail-to-rail I/O operational amplifier. This device operates from a single +2.7V to +6.5V supply, or from dual ±1.35V to ±3.25V supplies. They typically draw 1.2mA supply current, and are guaranteed to deliver 80mA output current. This device can be used in (1)Portable/Battery-Powered Audio Applications; (2)Portable Headphone Speaker Drivers; (3)Laptop/Notebook Computers; (4)Sound Ports/Cards; (5)Set-Top Boxes; (6)Cell Phones; (7)Hands-Free Car Phones (kits); (8)Signal Conditioning; (9)Digital-to-Analog Converter Buffers; (10)Transformer/Line Drivers; (11)Motor Drivers.

Parametrics

MAX4167ESA absolute maximum ratings: (1)Supply Voltage (VCC to VEE): 7V; (2)IN_+, IN_-, SHDN: (VEE - 0.3V) + (VCC + 0.3V); (3)OUT_ (shutdown mode): (VEE - 0.3V) + (VCC + 0.3V); (4)Operating Temperature Range: -40°C to +85°C; (5)Junction Temperature: +150°C; (6)Storage Temperature Range: -65°C to +150°C; (7)Lead Temperature (soldering, 10s): +300°C.

Features

MAX4167ESA features: (1)80mA (min) Output Drive Capability; (2)Rail-to-Rail Input Common-Mode Voltage Range; (3)Rail-to-Rail Output Voltage Swing; (4)1.2mA Supply Current per Amplifier; (5)+2.7V to +6.5V Single-Supply Operation; (6)5MHz Gain-Bandwidth Product; (7)250uV Offset Voltage; (8)120dB Voltage Gain (RL = 100k402para;); (9)88dB Power-Supply Rejection Ratio; (10)No Phase Reversal for Overdriven Inputs; (11)Unity-Gain Stable for Capacitive Loads to 250pF; (12)Low-Power Shutdown Mode:; (13)Reduces Supply Current to 38uA Places Outputs in High-Impedance State.
