Product Summary

The MDM1000 is a single axis motor drive with integrated interface to the National Instruments NI-73xx series motion controller. Several drive options are available including 2 digital servo drives, and one stepper drive. The MDM1000 operates directly from line voltage to operate the motor at a bus voltage specified during time of order. The interface to the NI-73xx controller is via the MOTION I/O connector on both the MDM1000 and 73xx controller. Connections to the axis are through the Primatics standard servo or stepper axis connector described in section 5.3.5.

Diagrams

MDM1000 block diagram
