P6KE33CA

P6KE33CA, Transient Voltage Suppressor, DO, 600W, 100A, Fairchild Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.50~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	4.00 / Piece
301 ~ 600 :	3.80 / Piece
601 ~ 1000 :	3.50 / Piece

PartNumber:: P6KE33CA

Brand:: Fairchild Semiconductor - Fairchild | Pack: DO | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-03

From Other Seller

Part Number:P6KE33CA
US $3.50 - 4.00
Quantity:

piece

Product Summary

The P6KE33CA is a Transient Voltage Suppressor.

Parametrics

P6KE33CA absolute maximum ratings: (1)PPPM, Peak Pulse Power Dissipation at TA=25℃, TP=1ms minimum: 600 W; (2)IPPM, Peak Pulse Current: see table A; (3)PD, Steady State Power Dissipation .375 " lead length @ TA = 75℃: 5.0 W; (4)if(surge), Peak Forward Surge Current; (5)superimposed on rated load (JEDEC method) (Note 1): 100 A; (6)Tstg, Storage Temperature Range: -65 to +175℃; (7)TJ, Operating Junction Temperature: -65 to +175℃.

Features

P6KE33CA features: (1)Glass passivated junction; (2)600W Peak Pulse Power capability at 1.0 ms; (3)Excellent clamping capability; (4)Low incremental surge resistance; (5)Fast response time; typically less than 1.0 ps from 0 volts to BV for unidirectional and 5.0 ns for bidirectional; (6)Typical IR less than 1.0μA above 10V.
