S29GL064N90TFI040

mirrorBit flash, 3.0V, 200mA, TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: S29GL064N90TFI040

Brand:: SPANSION - spansion | Pack: TSSOP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Alice's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-16

From Other Seller

Part Number:S29GL064N90TFI040
US $1.00 - 2.00
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The S29GL064N90TFI040 is a 3.0-Volt single-power Flash memory manufactured using 110nm MirrorBit technology. The S29GL064N90TFI040 is a 64-Mb device organized as 4,194,304 words or 8,388,608 bytes. The S29GL064N90TFI040 requires only a single 3.0-Volt power supply for both read and write functions. The S29GL064N90TFI040 is entirely command set compatible with the JEDEC single-power-supply Flash standard.

Parametrics

S29GL064N90TFI040 absolute maximum ratings: (1) Storage Temperature, Plastic Packages: -65°C to +150°C; (2) Ambient Temperature with Power Applied: -65°C to +125°C; (3) Voltage with Respect to Ground, VCC: -0.5V to +4.0V, A9, OE#, ACC and RESET# : -0.5V to +12.5V, All other pins: -0.5V to Vcc +0.5V; (4) Output Short Circuit Current: 200mA.

Features

S29GL064N90TFI04 features: (1) Single power supply operation; (2) Manufactured on 110 nm MirrorBit process technology; (3) Secured Silicon Sector region; (4) Flexible sector architecture; (5) Compatibility with JEDEC standards; (6) 20-year data retention typical; (7) 16-word/32-byte write buffer which reduces overall programming time for multiple-word updates; (8) CReady/Busy# output (RY/BY#) detects program or erase cycle completion.
