Product Summary

The SC32442BL-43S is a RS-232 transceivers solution intended for portable or handheld applications such as notebook or palmtop computers. The SC32442BL-43S has a high-efficiency, charge-pump power supply that requires only 0.1μF capacitors in 3.3V operation. This charge pump allows the SC32442BL-43S to deliver true RS-232 performance from a single power supply ranging from +3.3V to +5.0. This series is ideal for portable or hand-held applications such as notebook or palmtop computers.

Parametrics

SC32442BL-43S absolute maximum ratings: (1)Input Voltages: TxIN, EN: -0.3V to +6.0V, RxIN: ±15V; (2)Output Voltages: TxOUT: ±15V, RxOUT: -0.3V to (VCC + 0.3V); (3)Short-Circuit Duration: TxOUT: Continuous, Storage Temperature: -65°C to +150°C; (4)VCC: -0.3V to +6.0V; (5)V+ (NOTE 1): -0.3V to +7.0V; (6)V- (NOTE 1): +0.3V to -7.0V; (7)V+ + |V-| (NOTE 1): +13V; (8)ICC (DC VCC or GND current): ±100mA.

Features

SC32442BL-43S features: (1)Meets true EIA/TIA-232-F Standards from a +3.0V to +5.5V power supply; (2)Minimum 120Kbps Data Rate Under Full Load; (3)1μA Low-Power Shutdown with Receivers Active (SP3222E); (4)Interoperable with RS-232 down to +2.7V power source; (5)Enhanced ESD Specifications: ±15kV Human Body Model, ±15kV IEC1000-4-2 Air Discharge, ±8kV IEC1000-4-2 Contact Discharge.

Diagrams

SC32442BL-43S block diagram
