Product Summary
The SI3215-FM is a proslic programmable CMOS SLIC/codec that provides a complete analog telephone interface ideal for customer premise equipment (CPE) applications. The SI3215-FM integrates subscriber line interface circuit (SLIC), codec, and battery generation functionality into a single CMOS integrated circuit. The integrated battery supply continuously adapts its output voltage to minimize power and enables the entire solution to be powered from a single 3.3 V (Si3215M only) or 5 V supply. The applications of the SI3215-FM include Voice-over-broadband systems: DSL, cable, wireless, PBX/IP-PBX/key telephone systems, Terminal adapters: ISDN, Ethernet, USB.
Parametrics
SI3215-FM absolute maximum ratings: (1)DC Supply Voltage VDDD, VDDA1, VDDA2: -0.5 to 6.0 V; (2)Input Current, Digital Input Pins IIN: ±10 mA; (3)Digital Input Voltage VIND: -0.3 to (VDDD + 0.3) V; (4)Operating Temperature Range2 TA: -40 to 100℃; (5)Storage Temperature Range TSTG: -40 to 150℃; (6)TSSOP-38 Thermal Resistance, Typical, θJA: 70℃/W; (7)QFN-38 Thermal Resistance, Typical, θJA: 35℃/W; (8)Continuous Power Dissipation2, PD: 0.7 W.
Features
SI3215-FM features: (1)Performs all BORSCHT functions; (2)Software-programmable internal balanced ringing up to 90 VPK; (3)(5 REN up to 4 kft, 3 REN up to 8 kft); (4)Integrated battery supply with dynamic voltage output, On-chip dc-dc converter continuously minimizes power in all operating modes; Entire solution can be powered from a single 3.3 V or 5 V supply; 3.3 to 35 V dc input range; Dynamic 0 to –94.5 V output; Low-cost inductor and high-efficiency transformer versions supported; (5)Software-programmable linefeed parameters: Ringing frequency, amplitude, cadence, and waveshape, 2-wire ac impedance and hytrid; Constant current feed (20 to 41 mA); Loop closure and ring trip thresholds and filtering; (6)Software-programmable signal generation and audio processing: Phase-continuous FSK (caller ID) generation, Dual audio tone generators; Smooth and abrupt polarity reversal; μ-Law/A-Law and 16-bit linear PCM audio; (7)Extensive test and diagnostic features; Multiple voice loopback test modes; Real time dc linefeed measurement; GR-909 line test capabilities; (8)SPI and PCM bus digital interfaces; (9)Extensive programmable interrupts; (10)100% software-configurable global solution; (11)Ideal for customer premise equipment applications; (12)Lead-free and RoHS-compliant packages available.
Diagrams
