Product Summary
The SKY65225-12 is a WLAN 802.11n 2 x 2 MIMO Intera Front-End Module combines two complete dual-band transmit/receive chains in one compact RF front end module optimized for 2 x 2 MIMO (multiple in-multiple out) operation, in compliance with the 802.11n draft standard. The SKY65225-12 includes two 5 GHz PAs and two 2 GHz PAs, each with integrated input filtering for 3–4 GHz rejection, and two temperaturecompensated, directional power detectors with 20 dB dynamic range.
Parametrics
SKY65225-12 absolute maximum ratings: (1)VCC, VCC: -0.3 to 5.5 V; (2)PU0g, PU1g, PU0a, PU1a, PU: -0.3 to 5.5 V; (3)T0g,T1g,T0a,T1a, RFin: 10 dBm; (4)Operating temperature range, TOP: 0 to 85℃; (5)Storage temperature range, TSTO: -65 to 125℃; (6)Moisture sensitivity level, MSL-3: 250℃; (7)Thermal resistance, θJC: 60 ℃/W.
Features
SKY65225-12 features: (1)Two full dual-band transmit/receive chains; (2)PCIe, miniPCI, Cardbus, and access point applications; (3)Backward-compatible with 802.11a/b/g standards; (4)POUT @ 2.5% EVM: 16 dBm (-11a); 19 dBm (-11b); 19 dBm (-11g); (5)Gain matching: <1.0 dB @ 2 GHz, 2.0 dB @ 5 GHz; (6)Single 3.0–3.6 V power supply, internal voltage regulation; (7)Temperature-compensated PA bias networks and directional power detection; (8)Separate digital controls for each PA; (9)Package size: 10 x 14 x 0.9 mm; (10)Lead (Pb)-free and RoHS-compliant MSL-3 @ 250℃ per JEDEC J-STD-020.
Diagrams
