Product Summary
The SN74HC541NSR is an octal buffer and line driver. The performance of the SN74HC541NSR and a pinout with inputs and outputs on opposite sides of the package. This arrangement greatly facilitates printed circuit board layout. The 3-state outputs are controlled by a two-input NOR gate. If either output-enable (OE1 or OE2) input is high, all eight outputs are in the high-impedance state. The SN74HC541NSR provides true data at the outputs.
Parametrics
SN74HC541NSR absolute maximum ratings: (1)Supply voltage range: –0.5 V to 7 V; (2)Input clamp current, IIK (VI < 0 or VI > VCC): ±20 mA; (3)Output clamp current, IOK (VO < 0 or VO > VCC): ±20 mA; (4)Continuous output current, IO (VO = 0 to VCC): ±35 mA; (5)Continuous current through VCC or GND: ±70 mA; (6)Package thermal impedance, θJA (see Note 2): 60℃/W; (7)Storage temperature range: –65℃ to 150℃.
Features
SN74HC541NSR features: (1)Wide Operating Voltage Range of 2 V to 6 V; (2)High-Current 3-State Outputs Drive Bus; (3)Lines Directly or Up To 15 LSTTL Loads; (4)Low Power Consumption, 80-μA Max ICC; (5)Typical tpd = 10 ns; (6)±6-mA Output Drive at 5 V; (7)Low Input Current of 1 μA Max; (8)Data Flow-Through Pinout (All Inputs on Opposite Side From Outputs).
Diagrams
