SN74LVT16244BDGGR

buffer/receiver, 5V, 128mA, TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	3.00 / Piece
301 ~ 600 :	2.80 / Piece
601 ~ 1000 :	2.50 / Piece

PartNumber:: SN74LVT16244BDGGR

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-09

From Other Seller

Part Number:SN74LVT16244BDGGR
US $2.50 - 3.00
Quantity:

piece

Product Summary

The SN74LVT16244BDGGR is a 16-bit buffer and line driver designed for low-voltage (3.3-V) V operation, but can be used as four4-bit buffers, two 8-bit buffers, or one 16-bit buffer. provide true outputs and symmetricalactive-low output-enable (OE) inputs.

Parametrics

SN74LVT16244BDGGR absolute maximum ratings: (1) Supply voltage range Vcc: -0.5 to 4.6V; (2) Input voltage range VI: -0.5 to 7V; (3) Voltage range applied to any output in the high-impedance or power-off state Vo: -0.5 to 7V; (4) Voltage range applied to any output in the high state Vo: -0.5 to Vcc +0.5V; (5) Input clamp current IIK: -50mA (VI<0) ; (6) Output clamp current IOK: -50mA (Vo<0) ; (7) Storage temperature range Tstg: -65 to 150°C.

Features

SN74LVT16244BDGGR features: (1) Member of the Texas Instruments Widebus Family; (2) State-of-the-Art Advanced BiCMOS Technology (ABT) Design for 3.3-V Operation and Low Static-Power Dissipation; (3) Support Mixed-Mode Signal Operation (5V Input and Output Voltages With 3.3V Vcc ) ; (4) Support Unregulated Battery Operation Downto 2.7V; (5) Typical V (Output Ground Bounce)<0.8V at Vcc=3.3V, TA=25°C; (6) Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II; (7) ESD Protection Exceeds JESD 22.
