Product Summary

The TMS320C6415TGIZ is a fixed-point digital signal processor. The TMS320C6415TGIZ is a high-performance fixed-point DSP generation in the TMS320C6000 DSP platform. The device is based on the second-generation high-performance, advanced VelociTI very-long-instruction-word (VLIW) architecture (VelociTI.2.) developed by Texas Instruments (TI), making the DSP an excellent choice for wireless infrastructure applications. The C64x. is a code-compatible member of the C6000. DSP platform.

Parametrics

TMS320C6415TGIZ absolute maximum ratings: (1)Supply voltage ranges: CVDD: -0.5 V to 1.5 V; (2)DVDD: -0.5 V to 4.4 V; (3)Input voltage ranges: (except PCI), VI: -0.5 V to 4.4 V; (4)(PCI), VIP [C6415T and C6416T only]: -0.5 V to DVDD + 0.5 V; (5)Output voltage ranges: (except PCI), VO: -0.5 V to 4.4 V; (6)(PCI), VOP [C6415T and C6416T only]: -0.5 V to DVDD + 0.5 V; (7)Operating case temperature ranges, TC: (default): 0℃ to 90℃; (8)(A version) [A-600, A-720, A.850 only]: -40℃ to 105℃; (9)Storage temperature range, Tstg: -65℃ to 150℃.

Features

TMS320C6415TGIZ features: (1)Highest-Performance Fixed-Point DSPs, 1.67-/1.39-/1.17-/1-ns Instruction Cycle; 600-/720-/850-MHz, 1-GHz Clock Rate; Eight 32-Bit Instructions/Cycle; Twenty-Eight Operations/Cycle; 4800, 5760, 6800, 8000 MIPS; Fully Software-Compatible With C62x.; C6414/15/16 Devices Pin-Compatible; Extended Temperature Devices Available; (2)VelociTI.2. Extensions to VelociTI, Advanced Very-Long-Instruction-Word (VLIW) TMS320C64x. DSP Core; Eight Highly Independent Functional Units With VelociTI.2. Extensions: Six ALUs (32-/40-Bit), Each Supports Single 32-Bit, Dual 16-Bit, or Quad, 8-Bit Arithmetic per Clock Cycle; Two Multipliers Support; (3)Four 16 x 16-Bit Multiplies (32-Bit Results) per Clock Cycle or, Eight 8 x 8-Bit Multiplies (16-Bit Results) per Clock Cycle; Non-Aligned Load-Store Architecture; 64 32-Bit General-Purpose Registers; Instruction Packing Reduces Code Size; All Instructions Conditional; (4)Instruction Set Features, Byte-Addressable (8-/16-/32-/64-Bit Data); 8-Bit Overflow Protection; Bit-Field Extract, Set, Clear; Normalization, Saturation, Bit-Counting; VelociTI.2. Increased Orthogonality; (5)VCP [C6416T Only], Supports Over 833 7.95-Kbps AMR; Programmable Code Parameters.

Diagrams

TMS320C6415TGIZ block diagram
