TPS2065DR

TPS2065DR, current-limited, power-distribution switch, SOP, -0.3 V to 6 V, 1A, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.50~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 200 :	4.00 / Piece
201 ~ 500 :	3.80 / Piece
501 ~ 1000 :	3.50 / Piece

PartNumber:: TPS2065DR

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-16

From Other Seller

Part Number:TPS2065DR
US $3.50 - 4.00
Quantity:

piece

Product Summary

The TPS2065DR is a power-distribution switch intended for applications where heavy capacitive loads and short-circuits are likely to be encountered. This device incorporates 70-mΩ N-channel MOSFET power switches for power-distribution systems that require multiple power switches in a single package. Each switch is controlled by a logic enable input. Gate drive is provided by an internal charge pump designed to control the power-switch rise times and fall times to minimize current surges during switching. The applications of the TPS2065DR include Heavy Capacitive Loads, Short-Circuit Protections.

Parametrics

TPS2065DR absolute maximum ratings: (1)Input voltage range, VI(IN): -0.3 V to 6 V; (2)Output voltage range, VO(OUT), VO(OUTx): -0.3 V to 6 V; (3)Input voltage range, VI(EN), VI(EN), VI(ENx), VI(ENx): -0.3 V to 6 V; (4)Voltage range, VI(OC), VI(OCx): -0.3 V to 6 V; (5)Continuous output current, IO(OUT), IO(OUTx): Internally limited; (6)Continuous total power dissipation: See Dissipation Rating Table; (7)Operating virtual junction temperature range, TJ: -40℃ to 125℃; (8)Storage temperature range, Tstg: -65℃ to 150℃.

Features

TPS2065DR features: (1)70-mΩ High-Side MOSFET; (2)1-A Continuous Current; (3)Thermal and Short-Circuit Protection; (4)Accurate Current Limit(1.1 A min, 1.9 A max); (5)Operating Range: 2.7 V to 5.5 V; (6)0.6-ms Typical Rise Time; (7)Undervoltage Lockout; (8)Deglitched Fault Report (OC); (9)No OC Glitch During Power Up; (10)1-mA Maximum Standby Supply Current; (11)Bidirectional Switch; (12)Ambient Temperature Range: -40℃ to 85℃; (13)Built-in Soft-Start; (14)UL Listed - File No. E169910.
