Product Summary

The cg7161am is a 70A standard recovery diode. It is used in Converters, Power supplies, Machine tool controls, Battery charges.

Parametrics

cg7161am absolute maximum ratings: (1)IF(AV): 70 A; 140℃ at Tc; (2)IF(RMS): 110 A; (3)IFSM: 1200A AT 50 Hz; 1250A at 60 Hz ; (4)I2t: 7100A2s at 50 Hz; 6450A2s at 60 Hz; (5)VRRM: 100 to 1200 V; (6)TJ: - 65 to 180℃.

Features

cg7161am features: (1)High surge current capability; (2)Designed for a wide range of applications; (3)Stud cathode and stud anode version; (4)Leaded version available; (5)Types up to 1600 V VRRM; (6)RoHS compliant; (7)Designed and qualified for industrial level.

Diagrams

cg7161am block diagram
