Product Summary

The 74HC153AP is a 4-to-16 line decoder/demultiplexer. The 74HC153AP is a high-speed Si-gate CMOS device and is pin compatible with low power Schottky TTL(LSTTL). It is specified in compliance with JEDEC standard no. 7A. The 74HC153AP accepts four active HIGH binary address inputs and provide 16 mutually exclusive active LOW outputs. The 2-input enable gate of the 74HC153AP can be used to strobe the decoder to eliminate the normal decoding “glitches” on the outputs, or it can be used for the expansion of the decoder.

Parametrics

74HC153AP absolute maximum ratings: (1)supply voltage: -0.5V to +7.0V; (2)input diode current: ±20mA; (3)output diode current: ±20mA; (4)output source or sink current: ±25mA; (5)VCC or GND current: ±50mA; (6)storage temperature: -65 to +150℃; (7)power dissipation: 300mW.

Features

74HC153AP features: (1)16-line demultiplexing capability; (2)Decodes 4 binary-coded inputs into one of 16 mutually exclusive outputs; (3)2-input enable gate for strobing or expansion; (4)Output capability: standard; (5)ICC category: MSI.

Diagrams

74HC153AP block diagram
