AFBR-57D7APZ

AFBR-57D7APZ, Small Form Pluggable Low Voltage Electrical Transceiver, BGA, -0.5 to 3.6 V, 350mA, AVAGO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	3.00 / Piece
301 ~ 600 :	2.80 / Piece
601 ~ 1000 :	2.50 / Piece

PartNumber:: AFBR-57D7APZ

Brand:: AVAGO TECHNOLOGIES LIMITED - Avago | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-15

From Other Seller

Part Number:AFBR-57D7APZ
US $2.50 - 3.00
Quantity:

piece

Product Summary

The AFBR-57D7APZ is a Small Form Pluggable Low Voltage Electrical Transceiver from Avago Technologies off er full-duplex throughput of 1000 Mbps by transporting data over shielded and unshielded twisted pair category 5 cable with 5-level PAM (Pulse Amplitude Modulation) signals. The applications of the AFBR-57D7APZ include Switch to switch interface, Switched backplane applications, File server interface.

Parametrics

AFBR-57D7APZ absolute maximum ratings: (1)Storage Temperature, TS: -40 to +75℃; (2)Case Temperature, TC: -40 to +75℃; (3)Relative Humidity, RH: 5 to 95 %; (4)Module Supply Voltage, VCCT,R: -0.5 to 3.6 V; (5)Data/Control Input Voltage, VI: -0.5 to VCC V; (6)Sense Output Current -LOS: ID to NA mA.

Features

AFBR-57D7APZ features: (1)RoHS-6 Compliant (see Table 1); (2)Designed for Industry-Standard, MSA Compliant Small Form Factor Pluggable (SFP) Ports; (3)Compatible with IEEE 802.3:2000; (4)Custom RJ-45 connector with integrated magnetics; (5)Link lengths at 1.25 Gbd: up to 100 m per IEEE802.3; (6)Low power, high performance 1.25 Gbd SerDes integrated in module; (7)Single +3.3 V power supply operation; (8)Auto-negotiation per IEEE 802.3:2000 Clause 28 (Twisted Pair) and Clause 37 (1000BASE-X); (9)Compatible to both shielded and unshielded twisted pair category 5 cable; (10)Two confi gurations: ABCU-5700RZ: RX_LOS enabled; ABCU-5710RZ: RX_LOS disabled; (11)Rated for Commercial Temperature applications (0 - 70℃); (12)10/100/1000 BASE-T operation in host systems with SGMII interface.
