Product Summary

The AR6102G-BM2D-R is a dual, low power, high speed amplifier designed to operate on ±5 V supplies. The AR6102G-BM2D-R features unique transimpedance linearization circuitry. This allows it to drive video loads with excellent differential gain and phase performance on only 50 mW of power per amplifier. The AR6102G-BM2D-R is a current feedback amplifier and features gain flatness of 0.1 dB to 60 MHz while offering differential gain and phase error of 0.01% and 0.02°.

Parametrics

AR6102G-BM2D-R absolute maximum ratings: (1)Supply Voltage: 12.6 V; (2)Internal Power Dissipation: Plastic DIP Package (N): 1.3W, Small Outline Package (R): 0.9W, μSOIC Package (RM): 0.6W; (3)Input Voltage (Common Mode): ±VS; (4)Differential Input Voltage: ±1.2 V; (5)Output Short Circuit Duration: Observe Power Derating Curves; (6)Storage Temperature Range N, R, RM: –65℃ to +125℃; (7)Operating Temperature Range (A Grade): –40℃ to +85℃; (8)Lead Temperature Range (Soldering 10 sec): +300℃.

Features

AR6102G-BM2D-R features: (1)Excellent Video Specifications (RL = 150 V, G = +2): Gain Flatness 0.1 dB to 60 MHz, 0.01% Differential Gain Error, 0.028 Differential Phase Error; (2)Low Power: 5.5 mA/Amp Max Power Supply Current (55 mW); (3)High Speed and Fast Settling: 600 MHz, –3 dB Bandwidth (G = +1), 500 MHz, –3 dB Bandwidth (G = +2), 1200 V/ms Slew Rate, 16 ns Settling Time to 0.1%.

Diagrams

AR6102G-BM2D-R block diagram
