AT25DF321A-SH-B

AT25DF321A-SH-B, interface Flash memory device, 32Mbit, 100MHz, BGA, 2.7 V to 3.6 V, ATMEL Corporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	5.00 / Piece
101 ~ 1000 :	4.00 / Piece
1001 ~ 10000 :	3.00 / Piece

PartNumber:: AT25DF321A-SH-B

Brand:: ATMEL Corporation - ATMEL | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-26

From Other Seller

Part Number:AT25DF321A-SH-B
US $3.00 - 5.00
Quantity:

piece

Product Summary

The AT25DF321A-SH-B is a serial interface Flash memory device designed for use in a wide variety of high-volume consumer based applications in which program code is shadowed from Flash memory into embedded or external RAM for execution. The flexible erase architecture of the AT25DF321A-SH-B, with its erase granularity as small as 4-Kbytes, makes it ideal for data storage as well, eliminating the need for additional data storage EEPROM devices.

Parametrics

AT25DF321A-SH-B absolute maximum ratings: (1)Temperature under Bias: -55℃ to +125℃ ; (2)Storage Temperature: -65℃ to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +4.1V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.5V.

Features

AT25DF321A-SH-B features: (1)Single 2.7V - 3.6V Supply; (2)Serial Peripheral Interface (SPI) Compatible: Supports SPI Modes 0 and 3; Supports RapidS Operation; Supports Dual-Input Program and Dual-Output Read; (3)Very High Operating Frequencies: 100 MHz for RapidS; 85 MHz for SPI; Clock-to-Output (tV) of 5 ns Maximum; (4)Flexible, Optimized Erase Architecture for Code + Data Storage Applications: Uniform 4-Kbyte Block Erase; Uniform 32-Kbyte Block Erase; Uniform 64-Kbyte Block Erase; Full Chip Erase; (5)64 Sectors of 64-Kbytes Each; (6)Hardware Controlled Locking of Protected Sectors via WP Pin; (7)Sector Lockdown; (8)Make Any Combination of 64-Kbyte Sectors Permanently Read-Only; (9)128-Byte Programmable OTP Security Register; (10)Flexible Programming: Byte/Page Program (1 to 256 Bytes); (11)Fast Program and Erase Times; (12)Program and Erase Suspend/Resume; (13)Automatic Checking and Reporting of Erase/Program Failures; (14)Software Controlled Reset; (15)JEDEC Standard Manufacturer and Device ID Read Methodology; (16)Low Power Dissipation; (17)Endurance: 100,000 Program/Erase Cycles; (18)Data Retention: 20 Years; (19)Complies with Full Industrial Temperature Range.
