AT89S8253-24JU

AT89S8253-24JU, low-power, high-performance CMOS 8-bit microcontroller, 6.6V, 15.0 mA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	5.00 / Piece
101 ~ 1000 :	4.00 / Piece
1001 ~ 10000 :	3.00 / Piece

PartNumber:: AT89S8253-24JU

Brand:: ATMEL Corporation - Atmel | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-21

From Other Seller

Part Number:AT89S8253-24JU
US $3.00 - 5.00
AT89S8253-24JU

US $1.20 - 1.20 / Piece
(0) Remove
AT89S8253-24JU

US $1.98 - 2.27 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT89S8253-24JU is a low-power, high-performance CMOS 8-bit microcontroller. The device is manufactured using Atmel’s high-density nonvolatile memory technology and is compatible with the industry-standard MCS-51 instruction set and pinout. The on-chip downloadable Flash allows the program memory to be reprogrammed in-system through an SPI serial interface or by a conventional nonvolatile memory programmer.

Parametrics

AT89S8253-24JU absolute maximum ratings: (1)Operating Temperature: -55°C to +125°C; (2)Storage Temperature: -65°C to +150°C; (3)Voltage on Any Pin with Respect to Ground: -1.0V to +7.0V; (4)Maximum Operating Voltage: 6.6V; (5)DC Output Current: 15.0 mA.

Features

AT89S8253-24JU features: (1)64-byte User Signature Array; (2)2.7V to 5.5V Operating Range; (3)Fully Static Operation: 0 Hz to 24 MHz; (4)Three-level Program Memory Lock; (5)256 x 8-bit Internal RAM; (6)32 Programmable I/O Lines; (7)Three 16-bit Timer/Counters; (8)Nine Interrupt Sources; (9)Enhanced UART Serial Port with Framing Error Detection and Automatic Address Recognition; (10)Enhanced SPI (Double Write/Read Buffered) Serial Interface; (11)Low-power Idle and Power-down Modes; (12)Interrupt Recovery from Power-down Mode; (13)Programmable Watchdog Timer; (14)Dual Data Pointer; (15)Power-off Flag; (16)Flexible ISP Programming (Byte and Page Modes); (17)Page Mode: 64 Bytes/Page for Code Memory, 32 Bytes/Page for Data Memory; (18)Four-level Enhanced Interrupt Controller; (19)Programmable and Fuseable x2 Clock Option; (20)Internal Power-on Reset; (21)42-pin PDIP Package Option for Reduced EMC Emission; (22)Green (Pb/Halide-free) Packaging Option.
