Product Summary

The PS2134CF-G0548 is an ultra low level FET. It uses the latest Philips TrenchMOS technology to achieve the lowest possible on-state resistance in a SOT96-1 (SO8) package. The applications of the PS2134CF-G0548 are (1)DC to DC converter; (2)Computer motherboards; (3)Switch mode power supplies.

Parametrics

PS2134CF-G0548 absolute maximum ratings: (1)VDS drain-source voltage: 20 V; (2)ID drain current (DC): 32A; (3)VGS gate-source voltage: ±10 V; (4)IDM peak drain current: -60A; (5)Ptot total power dissipation: 8.3 W; (6)Tstg storage temperature: 150℃; (7)T operating junction temperature: -55 to +150℃.

Features

PS2134CF-G0548 features: (1)DC to DC converter; (2)Computer motherboards; (3)Switch mode power supplies.

Diagrams

PS2134CF-G0548 block diagram
