BAS29

BAS29, Small Signal Diode, SOT, 120V, 200mA, Fairchild Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.50~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	4.00 / Piece
301 ~ 600 :	3.80 / Piece
601 ~ 1000 :	3.50 / Piece

PartNumber:: BAS29

Brand:: Fairchild Semiconductor - Fairchild | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-03

From Other Seller

Part Number:BAS29
US $3.50 - 4.00
Quantity:

piece

Product Summary

The BAS29 is a Small Signal Diode.

Parametrics

BAS29 absolute maximum ratings: (1)VRRM, Maximum Repetitive Reverse Voltage: 120 V; (2)IF(AV), Average Rectified Forward Current: 200 mA; (3)IFSM, Non-repetitive Peak Forward Surge Current, Pulse Width = 1.0 second: 1.0A; Pulse Width = 1.0 microsecond: 2.0A; (4)Tstg, Storage Temperature Range -55 to +150℃; (5)TJ, Operating Junction Temperature 150℃.

Features

BAS29 features: (1)VR, Breakdown Voltage IR = 1.0 mA: 120 V; (2)VF, Forward Voltage IF = 10 mA: 0.75V; IF = 50 mA: 0.84V; IF = 100 mA: 0.90V; IF = 200 mA: 1.00V; IF = 400 mA: 1.25V; (3)IR, Reverse Current VR = 90 V: 100nA; VR = 90 V, TA = 150℃: 100μA; (4)CT, Total Capacitance VR = 0, f = 1.0 MHz: 2.0 pF; (5)trr, Reverse Recovery Time IF = IR = 30 mA, IRR = 3.0 mA, RL = 100 Ω: 50 ns.
