Product Summary

The CP2056LQ is a Compact Power Line.

Parametrics

CP2056LQ absolute maximum ratings: (1)PSM, maximum non-repetitive peak pulse power: 1.5kW; (2)Ptot, total continuous power dissipation: 5W; (3)ISM, maximum non-repetitive peak pulse current: see tables; (4)VR, stand-off voltage: see tables; (5)Tj, maximum junction temperature: 175℃; (6)Tstg, Storage temperature range: -55 to 175℃.

Diagrams

CP2056LQ block diagram
