Product Summary

The IRFB4410ZPBF is a recifier. And the applications of the IRFB4410ZPBF include: High Efficiency Synchronous Rectification in SMPS, Uninterruptible Power Supply, High Speed Power Switching and Hard Switched and High Frequency Circuits.

Parametrics

IRFB4410ZPBF absolute maximum ratings: (1) Continuous Drain Current, V@10V (Silicon Limited) ID@Tc=25°C: 97A; (2) Continuous Drain Current, VGS@10V (Silicon Limited) D@Tc=100°C: 69A; (3) ontinuous Drain Current, V@10V (Package Limited) ID@Tc=25°C: 75A; (4) Pulsed Drain Current IDM: 390A; (5) Maximum Power Dissipation PD@Tc=25°C: 230W; (6) Linear Derating Factor: 1.5W/°C; (7) Gate-to-Source Voltage VGS: ±20V; (8) Peak Diode Recovery dv/dt: 16V/ns; (9) Operating Junction and Storage Temperature Range Tj, Tstg: -55 to +175°C; (10) Soldering Temperature, for 10 seconds 1.6mm from case) : 300°C; (11) Mounting torque, 6-32 or M3 screw: 10lb in (1.1N m) .

Features

IRFB4410ZPBF features: (1) Improved Gate, Avalanche and Dynamic dV/dt Ruggedness; (2)Fully Characterized Capacitance and Avalanche SOA; (3) Enhanced body diode dV/dt and dI/dt Capability; (4) Lead-Free.

Diagrams

IRFB4410ZPBF Unclamped Inductive Test Circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
IRFB4410ZPBF
IRFB4410ZPBF
International Rectifier
MOSFET MOSFT 100V 97A 9mOhm 83nC Qg
Data Sheet
0-1: $1.72
1-25: $1.12
25-100: $0.80
100-250: $0.76
