Product Summary

The LCMXO640C3FTN256C is a complex programmable logic device. It is optimized to meet the requirements of applications traditionally addressed by CPLDs and low capacity FPGAs.

Parametrics

LCMXO640C3FTN256C absolute maximum ratings: (1)Supply Voltage VCC: -0.5V to 3.75V; (2)Supply Voltage VCCAUX: -0.5V to 3.75V; (3)Output Supply Voltage VCCIO: -0.5V to 3.75V; (4)I/O Tristate Voltage Applied: -0.5V to 3.75V; (5)Dedicated Input Voltage Applied: -0.5V to 4.25V; (6)Storage Temperature (ambient): -65℃ to 150℃; (7)Junction Temp.: +125℃.

Features

LCMXO640C3FTN256C features: (1)Instant-on-powers up in microseconds; (2)Single chip, no external configuration memory required; (3)Excellent design security, no bit stream to intercept; (4)Reconfigure SRAM based logic in milliseconds; (5)SRAM and non-volatile memory programmable through JTAG port; (6)Supports background programming of non-volatile memory; (7)256 to 2280 LUT4s; (8)73 to 271 I/Os with extensive package options; (9)Density migration supported; (10)Lead free/RoHS compliant packaging.

Diagrams

LCMXO640C3FTN256C block diagram
