M29W320DB

M29W320DB, 32 Mbit non-volatile memory, BGA, -0.6 to 13.5V, STMicroelectronics

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	3.00 / Piece
301 ~ 600 :	2.80 / Piece
601 ~ 1000 :	2.50 / Piece

PartNumber:: M29W320DB

Brand:: STMicroelectronics - ST | Pack: BGA | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-10

From Other Seller

Part Number:M29W320DB
US $2.50 - 3.00
Quantity:

piece

Product Summary

The M29W320DB is a 32 Mbit (4Mb x8 or 2Mb x16) non-volatile memory that can be read, erased and reprogrammed. These operations can be performed using a single low voltage(2.7 to 3.6V) supply. On power-up the memory defaults to its Read mode where it can be read in the same way as a ROM or EPROM. The M29W320DB is divided into blocks that can be erased independently so it is possible to preserve valid data while old data is erased. Each block can be protected independently to prevent accidental Program or Erase commands from modifying the memory.

Parametrics

M29W320DB absolute maxing ratings: (1)TBIAS Temperature under bias: min=-50℃, max=125℃; (2)TSTG Storage temperature: min=-65℃ max=150℃; (3)VIO Input or Output voltage(1)(2): min=-0.6V, max=VCC+0.6V; (4)VCC Supply voltage: min=-0.6V, max=4V; (5)VID Identification voltage: min=-0.6V, max=13.5V; (6)VPP(3) Program voltage: min=-0.6V, max=13.5V.

Features

M29W320DB features: (1)Supply voltage: VCC=2.7V to 3.6V for Program, Erase and Read; VPP =12V for Fast Program (optional); (2)Access times: 70, 90ns; (3)Programming time: 10μs per byte/word typical; (4)67 Memory Blocks: 1 Boot Block (Top or Bottom Location), 2 Parameter and 64 Main Blocks; (5)Program/Erase controller: Embedded Byte/Word Program algorithms; (6)Erase Suspend and Resume modes: Read and Program another Block during Erase Suspend; (7)Unlock Bypass Program command: Faster Production/Batch Programming; (8)VPP/WP pin for fast Program and Write Protect; (9)Temporary Block Unprotection mode; (10)Common Flash Interface: 64 bit Security code.
