MAX16046ECB

MAX16046ECB, 12-Channel EEPROM-Programmable System Manager, QFP, -0.3V to +15V, 20mA, Maxwell Technologies

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	3.00 / Piece
301 ~ 600 :	2.80 / Piece
601 ~ 1000 :	2.50 / Piece

PartNumber:: MAX16046ECB

Brand:: Maxwell Technologies - Maxwell | Pack: QFP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-27

From Other Seller

Part Number:MAX16046ECB
US $2.50 - 3.00
Quantity:

piece

Product Summary

The MAX16046ECB is an EEPROM-configurable system manager monitor, sequence, track, and margin multiple system voltages. The MAX16046ECB manages up to twelve system voltages simultaneously. The device integrates an analog-to-digital converter (ADC) for monitoring supply voltages, digital-to-analog converters (DAC) for adjusting supply voltages, and configurable outputs for sequencing and tracking supplies (during power-up and powerdown). The applications of the MAX16046ECB include Servers, Workstations, Storage Systems, Networking/Telecom.

Parametrics

MAX16046ECB absolute maximum ratings: (1)VCC to GND: -0.3V to +15V; (2)EN, MON_, SCL, SDA, A0: -0.3V to +6V; (3)GPIO_, RESET (configured as open drain) to GND: -0.3V to +6V; (4)EN_OUT1–EN_OUT6 (configured as open drain) to GND: -0.3V to +12V; (5)EN_OUT7–EN_OUT12 (configured as open drain) to GND: -0.3V to +6V; GPIO_, EN_OUT_, RESET (configured as push-pull) to GND: -0.3V to (VDBP + 0.3V); (6)DBP, ABP to GND: -0.3V to the lower of 3V or (VCC + 0.3V); (7)TCK, TMS, TDI: -0.3V to +3.6V; (8)TDO: -0.3V to (VDBP + 0.3V); (9)DACOUT: -0.3V to (VABP + 0.3V).

Features

MAX16046ECB features: (1)Operates from 3V to 14V; (2)1% Accurate 10-Bit ADC Monitors 12/8 Inputs; (3)12/8 Monitored Inputs with 1 Overvoltage/1 Undervoltage/1 Selectable Limit; (4)12/8 8-Bit DAC Outputs for Margining or Voltage Adjustments; (5)Nonvolatile Fault Event Logger; (6)Power-Up and Power-Down Sequencing Capability; (7)12/8 Outputs for Sequencing/Power-Good Indicators; (8)Closed-Loop Tracking for Up to Four Channels; (9)Two Programmable Fault Outputs and One Reset Output; (10)Six General-Purpose Input/Outputs Configurable as: Dedicated Fault Output; Watchdog Timer Function; Manual Reset; Margin Enable Input; (11)I2C (with Timeout) and JTAG Interface; (12)EEPROM-Configurable Time Delays, Thresholds, and DAC Outputs; (13)100 Bytes of Internal User EEPROM; (14)-40℃ to +85℃ Operating Temperature Range.
