Product Summary

The PM8014 is a comprehensive line of four single output and five dual output DC/DC converter with output power from 10 to 12 Watts. The PM8014 offers excellent regulation with low ripple and noise, and is especially useful in applications where higher output power levels are needed in a compact module. A Pi input filter in all models minimizes reflected ripple current while also providing for input spike attenuation. Six sided continuous shielding, also standard, gives EMI/RFI suppression.

Parametrics

PM8014 absolute maximum ratings: (1)input voltage: 5V; (2)output voltage: 5V; (3)output current: 2000mA; (4)input current, no load: 250mA; full load: 3080mA; (5)regulation, line: ±0.02%; load: ±0.05%.

Features

PM8014 features: (1)Linear topology for low noise applications; (2)Tight line and load regulation; (3)Short circuit protection; (4)Pi input filter; (5)Six sided continuous shield; (6)No derating.

Diagrams

PM8014 block diagram
