Product Summary

The SA8500V1.1 is an Axial Lead Transient Voltage Suppressor.

Parametrics

SA8500V1.1 absolute maximum ratings: (1)Peak power dissipation with a 10/1000μS waveform, PPP: 500W; (2)Peak pulse current with a 10/1000μS waveform, IPPM: see next table; (3)Power dissipation on infinite heatsink at TL=75℃, PD: 3W; (4)Peak forward surge current, 8.3ms single half sine-wave uni-directional only, IFSM: 70A; (5)Maximum instantaneous forward voltageat 25A for uni-directional only, VF: 3.5/5.0V; (6)Operating junction and storage temperature range, TJ,TSTG: -55 to +150℃.

Features

SA8500V1.1 features: (1)Glass passivated chip; (2)Low leakage; (3)500W peak pulse power capability with a 10/1000μs waveform, repetitive rate (dutycycle): 0.01%; (4)Uni and Bidirectional unit; (5)Excellent clamping capability; (6)Very fast response time; (7)Rohs compliant.

Diagrams

SA8500V1.1 block diagram
