SN65LVCP40RGZTG4

SN65LVCP40RGZTG4, DC to 4-GBPS dual 1:2 multiplexer/repeater/equalizer, QFN, -0.5 V to 6 V, 100W, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	3.00 / Piece
301 ~ 600 :	2.80 / Piece
601 ~ 1000 :	2.50 / Piece

PartNumber:: SN65LVCP40RGZTG4

Brand:: Texas Instruments - TI | Pack: QFN | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-24

From Other Seller

Part Number:SN65LVCP40RGZTG4
US $2.50 - 3.00
Quantity:

piece

Product Summary

The SN65LVCP40RGZTG4 is a signal conditioner and data multiplexer optimized for backplanes. Input equalization and programmable output preemphasis support data rates up to 4 Gbps. Common applications are redundancy switching, signal buffering, or performance improvements on legacy backplane hardware. The applications of the SN65LVCP40RGZTG4 include Bidirectional Link Replicator, Signal Conditioner, XAUI 802.3ae Protocol Backplane Redundancy, Host Adapter (Applications With Internal and External Connection to SERDES), Signaling Rates DC to 4 Gbps Including XAUI, GbE, FC, HDTV.

Parametrics

SN65LVCP40RGZTG4 absolute maximum ratings: (1)VCC Supply voltage range: -0.5 V to 6 V; (2)Control inputs, all outputs: -0.5 V to (VCC + 0.5 V); (3)Voltage range Receiver input: -0.5 V to 4 V; (4)Human Body Model(3) All pins: 4 kV; (5)ESD, Charged-Device Model(4) All pins: 500 V; (6)TJ, Maximum junction temperature: See Package Thermal Characteristics Table.

Features

SN65LVCP40RGZTG4 features: (1)Receiver Equalization and Selectable Driver Preemphasis to Counteract High-Frequency Transmission Line Losses; (2)Integration of Two-Serial Port; (3)Selectable Loopback; (4)Typical Power Consumption 650 mW; (5)30-ps Deterministic Jitter; (6)On-Chip 100-W Receiver and Driver Differential Termination Resistors Eliminate External Components and Reflection from Stubs; (7)3.3-V Nominal Power Supply; (8)48-Terminal QFN (Quad Flatpack) 7 mm × 7 mm × 1 mm, 0.5-mm Terminal Pitch; (9)Temperature Range: -40℃ to 85℃.
