Product Summary
The TPS2553 is a power-distribution switch intended for applications where precision current limiting is required or heavy capacitive loads and short circuits are encountered. The TPS2553 offers a programmable current-limit threshold between 75 mA and 1.3 A (typ) via an external resistor. Current-limit accuracy as tight as +/-6% can be achieved at the higher current-limit settings. The power-switch rise and fall times are controlled to minimize current surges during turn on/off. The applications of the TPS2553 inlucde USB Ports/Hubs, Digital TV, Set-Top Boxes, Mobile Phones and VOIP Phones.
Parametrics
TPS2553 absolute maximum ratings: (1)Voltage range on IN, OUT, EN or EN , ILIM, FAULT: -0.3 to 7 V; (2)Voltage range from IN to OUT: -7 to 7 V; (3)I O Continuous output current: Internally Limited; (4)Continuous FAULT sink current: 25 mA; (5)ILIM source current: 1 mA; (6)ESD, HBM: 2 kV; CDM: 500 V; (7)TJ, Maximum junction temperature: -40 to 150℃; (8)Tstg, Storage temperature: –65 to 150℃.
Features
TPS2553 features: (1)± 6% Current-Limit Accuracy at 1.3 A; (2)Meets USB Current-Limiting Requirements; (3)Backwards Compatible with TPS2550/51; (4)Adjustable Current Limit, 75 mA – 1300 mA (typ); (5)Constant-Current (TPS2552/53) and Latch-off (TPS2552-1/53-1) Versions; (6)Fast Overcurrent Response - 2- μ S (typ); (7)85-mΩ High-Side MOSFET (DBV Package); (8)Reverse Input-Output Voltage Protection; (9)Operating Range: 2.5 V to 6.5 V; (10)1- μ A Maximum Standby Supply Current; (11)Built-in Soft-Start; (12)15 kV ESD Protection per IEC 61000-4-2 (with External Capacitance).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TPS2553DBV1EVM-364 |
Texas Instruments |
Switch IC Development Tools TPS2553DBV1EVM-364 Eval Mod |
Data Sheet |
|
|
||||||||||||
|
TPS2553DBVEVM-364 |
Texas Instruments |
Switch IC Development Tools TPS2553DBVEVM-364 Eval Mod |
Data Sheet |
|
|
||||||||||||
|
TPS2553DBVR |
Texas Instruments |
Power Switch ICs - USB Adj Crnt-Ltd Pwr- Dist Sw |
Data Sheet |
|
|
||||||||||||
|
TPS2553DBVR-1 |
Texas Instruments |
Power Switch ICs - USB Adj Crnt-Ltd Pwr- Dist Sw |
Data Sheet |
|
|
||||||||||||
|
TPS2553DBVT |
Texas Instruments |
Power Switch ICs - USB Adj Crnt-Ltd Pwr- Dist Sw |
Data Sheet |
|
|
||||||||||||
|
TPS2553DBVT-1 |
Texas Instruments |
Power Switch ICs - USB Adj Crnt-Ltd Pwr- Dist Sw |
Data Sheet |
|
|
||||||||||||
|
TPS2553DRV1EVM-364 |
Texas Instruments |
Switch IC Development Tools TPS2553DRV1EVM-364 Eval Mod |
Data Sheet |
|
|
||||||||||||
|
TPS2553DRVEVM-364 |
Texas Instruments |
Switch IC Development Tools TPS2553DRV1EVM-364 Eval Mod |
Data Sheet |
|
|
||||||||||||
