TPS60500DGSR

TPS60500DGSR, high efficiency tep-down charge pump, MSOP, -0.3 V to 7 V, 250mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.50~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	5.00 / Piece
301 ~ 600 :	4.80 / Piece
601 ~ 1000 :	4.50 / Piece

PartNumber:: TPS60500DGSR

Brand:: Texas Instruments - TI | Pack: MSOP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-16

From Other Seller

Part Number:TPS60500DGSR
US $4.50 - 5.00
Quantity:

piece

Product Summary

The TPS60500DGSR is a step-down charge pump that generates a regulated, fixed 3.3-V, 1.8-V, 1.5-V, or adjustable output voltage. Only four small ceramic capacitors are required to build a complete high efficiency dc/dc charge pump converter. To achieve the high efficiency over a wide input voltage range, the charge pump automatically selects between three different conversion modes. The applications of the TPS60500DGSR include Personal Digital Assistants, DSP Core Supply, Cellular Phones, Portable Instruments, Internet Audio Player, PC Peripherals, USB Powered Applications.

Parametrics

TPS60500DGSR absolute maximum ratings: (1)Voltage range at VIN, EN, PG to GND: -0.3 V to 7 V; (2)Voltage range at OUT, FB to GND: -0.3 V to 3.6 V; (3)Voltage range at C1F+, C1F–, C2F+, C2F– to GND: -0.3 V to 7 V; (4)Continuous power dissipation: See Dissipation Rating Table; (5)Output current at OUT: 300 mA; (6)Storage temperature range, Tstg: -55℃ to 150℃; (7)Maximum junction temperature, TJ: 150℃.

Features

TPS60500DGSR features: (1)Regulated 3.3-V, 1.8-V, 1.5-V, or Adjustable Output Voltage; (2)Up to 250-mA Output Current; (3)1.8-V to 6.5-V Input Voltage; (4)Up to 90% Efficiency; (5)Output Voltage Tolerance 3% Over Line, Load, and Temperature Variation; (6)Device Quiescent Current Less Than 40 μA; (7)Output Voltage Supervisor Included (Power Good); (8)Internal Soft Start; (9)Load Isolated From Battery During Shutdown; (10)Overtemperature and Overcurrent Protected; (11)Micro-Small 10-Pin MSOP Package; (12)EVM Available, TPS60500EVM-193.
