74HC161D

74HC161D, Presettable synchronous 4-bit binary counter, SOP, 5.5V, 44MHz, NXP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	3.00 / Piece
301 ~ 600 :	2.80 / Piece
601 ~ 1000 :	2.50 / Piece

PartNumber:: 74HC161D

Brand:: NXP - NXP | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-28

From Other Seller

Part Number:74HC161D
US $2.50 - 3.00
Quantity:

piece

Product Summary

The 74HC161D is a Presettable synchronous 4-bit binary counter. It is pin compatible with low power Schottky TTL(LSTTL). The device is specified in compliance with JEDEC standard no. 7A. The The 74HC161D is a synchronous presettable binary counter which features an internal look-ahead carry and can be used for high-speed counting. Synchronous operation is provided by having all flip-flops clocked simultaneously on the positive-going edge of the clock (CP). The outputs (Q0 to Q3) of the 74HC161D may be preset to a HIGH or LOW level. A LOW level at the parallel enable input (PE) disables the counting action and causes the data at the data inputs(D0 to D3) to be loaded into the 74HC161D on the positive-going edge of the clock (providing that the set-up and hold time requirements for PE are met). Preset takes place regardless of the levels at count enable inputs(CEP and CET).

Parametrics

74HC161D absolute maximum ratigns:(1)propagation delay, CP to Qn: 19ns, CP to TC: 21ns, MR to Qn: 20ns, MR to TC: 20ns, CET to TC: 10ns; (2)maximum clock frequency: 44MHz; (3)input capacitance: 3.5pF; (4)power dissipation capacitance per package: 33pF.

Features

74HC161D features: (1)Synchronous counting and loading; (2)Two count enable inputs for n-bit cascading; (3)Positive-edge triggered clock; (4)Asynchronous reset; (5)Output capability: standard; (6)ICC category: MSI.
