Product Summary

The FJP13007H1TU is a High Voltage Fast-Switching NPN Power Transistor.

Parametrics

FJP13007H1TU absolute maximum ratings: (1)VCBO, Collector-Base Voltage: 700 V; (2)VCEO, Collector-Emitter Voltage: 400 V; (3)VEBO, Emitter-Base Voltage: 9 V; (4)IC, Collector Current (DC): 8 A; (5)ICP, Collector Current (Pulse): 16 A; (6)IB, Base Current: 4 A; (7)PC, Collector Dissipation (TC = 25℃): 80 W; (8)TJ, Junction Temperature: 150℃; (9)TSTG, Storage Temperature: -65 ~ 150℃.

Features

FJP13007H1TU features: (1)High Voltage Capability; (2)High Switching Speed; (3)Suitable for Electronic Ballast and Switching Mode Power Supply.

Diagrams

FJP13007H1TU block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
FJP13007H1TU
FJP13007H1TU

Fairchild Semiconductor

Transistors Bipolar (BJT) NPN Sil Transistor

Data Sheet

0-1: $0.47
1-25: $0.36
25-100: $0.29
100-250: $0.25
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
FJP13007H1TU
FJP13007H1TU

Fairchild Semiconductor

Transistors Bipolar (BJT) NPN Sil Transistor

Data Sheet

0-1: $0.47
1-25: $0.36
25-100: $0.29
100-250: $0.25
