FXL2T245L10X

FXL2T245L10X, Low Voltage Dual Supply 2-Bit Signal Translator, MicroPak, -0.5V to +4.6V, 50mA, Fairchild Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.50~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	4.00 / Piece
301 ~ 600 :	3.80 / Piece
601 ~ 1000 :	3.50 / Piece

PartNumber:: FXL2T245L10X

Brand:: Fairchild Semiconductor - Fairchild | Pack: MICRO SMDXT | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-03

From Other Seller

Part Number:FXL2T245L10X
US $3.50 - 4.00
Quantity:

piece

Product Summary

The FXL2T245L10X is a configurable dual-voltage-supply translator designed for both uni-directional and bi-directional voltage translation between two logic levels. The FXL2T245L10X allows translation between voltages as high as 3.6V to as low as 1.1V. The A Port tracks the VCCA level, and the B Port tracks the VCCB level. This allows for bi-directional voltage translation over a variety of voltage levels: 1.2V, 1.5V, 1.8V, 2.5V, and 3.3V. The FXL2T245L10X remains in 3-STATE until both VCCs reach active levels allowing either VCC to be powered-up first. Internal power down control circuits place the device in 3-STATE if either VCC is removed.

Parametrics

FXL2T245L10X absolute maximum ratings: (1)Supply Voltage, VCCA: -0.5V to +4.6V; VCCB: -0.5V to +4.6V; (2)DC Input Voltage (VI), I/O Port A: -0.5V to +4.6V; I/O Port B: -0.5V to +4.6V; (3)Control Inputs (T/R, OE): -0.5V to +4.6V; (4)Output Voltage (VO) (Note 2), Outputs 3-STATE: -0.5V to +4.6V; Outputs Active (An): -0.5V to VCCA + 0.5V; Outputs Active (Bn): -0.5V to VCCB + 0.5V; (5)DC Input Diode Current (IIK) VI < 0V: -50 mA; (6)DC Output Diode Current (IOK), VO < 0V: -50 mA; VO > VCC: +50 mA; (7)DC Output Source/Sink Current (IOH/IOL): -50 mA / +50 mA; (8)DC VCC or Ground Current per Supply Pin (ICC): ±100 mA; (9)Storage Temperature Range (TSTG): -65℃ to +150℃.

Features

FXL2T245L10X features: (1)Bi-directional interface between any 2 levels from 1.1V to 3.6V; (2)Fully configurable, inputs track VCC level; (3)Non-preferential power-up sequencing; either VCC may be powered-up first; (4)No power-up sequencing required; (5)Outputs remain in 3-STATE until active VCC level is reached; (6)Outputs switch to 3-STATE if either VCC is at GND; (7)Power-off protection; (8)Control inputs (T/R, OE) levels are referenced to VCCA; (9)voltage; (10)Packaged in 10-lead Pb-Free MicroPak (1.6mm x 2.1mm) package.
