Product Summary
The HBCU-5710R is a Low-Loss, High Frequency Snubber Capacitor designed for applications requiring optical reflective sensing. The HBCU-5710R contains a 655 nm (or 820 nm) LED emitter and a photodiode. A bifurcated aspheric lens is used to image the active areas of the emitter and detector to a single spot 4.27 mm (0.168 in.) in front of the package. The output signal is a current generated by the photodiode.
Parametrics
HBCU-5710R absolute maximum ratings: (1)Storage Temperature TS: -40 to +75 ℃; (2)Operating Temperature TA: -20 to +75 ℃; (3)Lead Soldering Temperature: 260 ℃; (4)Peak LED Forward Current Ifp: 100 mA 3 (HBCC-1580); (5)Reverse LED Input Voltage Vr: 5.0 V; (6)Photodiode Bias Vd: -0.3 to 6.0V.
Features
HBCU-5710R features: (1)Focused Emitter and Detector in a Single Package; (2)TO-5 Miniature Sealed Package; (3)Photodiode Output; (4)Choice of Resolutions (0.13 mm, 0.178 mm, 0.33 mm); (5)Two Wavelengths Available; 655 nm, 820 nm (see selection guide).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 HBCU-5710R |
Avago Technologies |
Fiber Optic Transmitters, Receivers, Transceivers 1000Base-T SFP TXCVR Cat5 UTP |
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
|
HBCU-5710R |
Avago Technologies |
Fiber Optic Transmitters, Receivers, Transceivers 1000Base-T SFP TXCVR Cat5 UTP |
Data Sheet |
Negotiable |
|
||||
