Product Summary
The HCPL-0700-500E is a low input current high gain split darlington optocoupler consists of an AlGaAs LED optically coupled to a high gain split darlington photodetector housed in a compact 8-pin small outline package. The HCPL-0700-500E has two channels per package for optimum mounting density. The split darlington configuration separating the input photodiode and the first stage gain from the output transistor permits lower output saturation voltage and higher speed operation than possible with conventional darlington phototransistor optocoupler. The applications of the HCPL-0700-500E include Digital logic ground isolation, Telephone ring detector, EIA-RS-232C line receiver, High common mode noise line receiver, μP bus isolation, Current loop receiver.
Parametrics
HCPL-0700-500E absolute maximum ratings: (1)DC/Average Forward Input Current, IF (avg): 20 mA; (2)Peak Forward Input Current (50% duty cycle, 1 ms P.W.), IF (pk): 40 mA; (3)Peak Transient Input Current-(≤1 μs P.W., 300 pps), IF (trans): 1.0 A; (4)Reverse Input Voltage, VR: 5 V; (5)Input Power Dissipation, PD: 35 mW; (6)Storage Temperature, TSTG: -40 to +125℃; (7)Operating Temperature, TOPR: -40 to +85℃.
Features
HCPL-0700-500E features: (1)Low input current -0.5 mA; (2)Superior CTR -2000%; (3)Superior CMR -10 kV/μs; (4)CTR guaranteed 0-70℃; (5)U.L. Recognized (file# E90700); (6)VDE 0884 recognized (file# 136616)-approval pending for HCPL-0730/0731; (7)BSI recognized (file# 8661, 8662)-HCPL-0700/0701 only.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HCPL-0700-500E |
Avago Technologies |
High Speed Optocouplers 100kBd 1Ch 0.5mA |
Data Sheet |
|
|
||||||||||||
