LAN9221-ABZJ

LAN9220-ABZJ, High-Performance 16-bit Non-PCI 10/100 Ethernet Controller, QFN, 6V, SMSC Corporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.50~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 300 :	4.00 / Piece
301 ~ 600 :	3.80 / Piece
601 ~ 1000 :	3.50 / Piece

PartNumber:: LAN9221-ABZJ

Brand:: SMSC Corporation - SMSC | Pack: QFN | D/C: 11+

Availability:: Supply Ability: 1000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Alice's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-04-22

From Other Seller

Part Number:LAN9221-ABZJ
US $3.50 - 4.00
Quantity:

piece

Product Summary

The LAN9220-ABZJ is a High-Performance 16-bit Non-PCI 10/100 Ethernet Controller. The applications of the LAN9220-ABZJ include Cable, satellite, and IP set-top boxes, Digital video recorders and DVD recorder/players, Digital TV, Digital media clients/servers and home gateways, Video-over IP solutions, IP PBX & video phones, Wireless routers & access points, High-end audio distribution systems.

Parametrics

LAN9220-ABZJ absolute maximum ratings: (1)Supply Voltage (VDDVARIO, VDD33REG, VDD33A): 0V to +3.6V; (2)Positive voltage on signal pins, with respect to ground: +6V; (3)Negative voltage on signal pins, with respect to ground: -0.5V; (4)Positive voltage on XTAL1/CLKIN, with respect to ground: +4.6V; (5)Positive voltage on XTAL2, with respect to ground: +2.5V; (6)Storage Temperature: -65℃ to +150℃; (7)Lead Temperature Range: Refer to JEDEC Spec. J-STD-020; (8)HBM ESD Performance: ±5kV.

Features

LAN9220-ABZJ features: (1)Optimized for high performance applications; (2)Efficient architecture with low CPU overhead; (3)Easily interfaces to most 16-bit embedded CPU’s; (4)1.8V to 3.3V variable voltage I/O accommodates wide range of I/O signalling without voltage level shifters; (5)Integrated PHY with HP Auto-MDIX support; (6)Integrated checksum offload engine helps reduce CPU load; (7)Low pin count and small body size package for small form factor system designs.
